The ZhenHuan H series constant voltage power supply 60 Watt is one black color, universal AC input voltage range from 100V-277VAC outdoor power supplies certified to meet UL cUL Class 2 and CE FCC safety approvals. The Power Transformer use low profile aluminum case with special input and output wiring makes the power solutions for different I.T.E, CCTV, Audio/Video, LED and home applications. Featuring PFC function of up to 0.95 and higher, IP65 IP67 environment Protection Rating for indoor or outdoor use, the H series ac to dc converter provide 5 years warranty and high efficient energy-saving.
Features:
． Class 2 Power Units
． Super compact Aluminum case
． UL/cUL CE SAA UKCA FCC RoHS
． IP65 IP67 - Indoor or Outdoor Use
． Work in the temperature range of-40℃~+50℃ under natural air cooling and heat dissipation
． Auto-Reset Protection for input/output overvoltage protection, input/output overcurrent protection, over temperature protection, over power protection and short circuit protection
| Input Voltage | 100~277V AC 47~63Hz | |||
| Power Factor | PF≧0 98/115VAC, PF≧0 95/230VAC, PF≧0.9/277VAC, full load | |||
| Model | KS-60A-12 | KS-60A-24 | KS-60A-36 | KS-60A-48 |
| Output Voltage | 12V | 24V | 36V | 48V |
| Rated Current | 5A | 2.5A | 1.67A | 1.25A |
| Rated Power | 60W | |||
| Ripple & Noise (max.) | 200mVp-p | 250mVp-p | 250mVp-p | 250mVp-p |
| Dimenion(L*W*H) |
188*58*36mm |
|||
Dimension Drawing:
| Package | Piece/Carton(pcs) | Dimension/Carton(mm) | Dimension/Brown Box(mm) | Piece Weight(KG) | Gross Weight/Carton(KG) |
| OEM package | 20 | 511 x 455 x 160 | 248 x 85 x 70 | 0.72 | 15 |
