The ZhenHuan H series constant voltage power supply 300 Watt 320Watt is one black color, universal AC input voltage range from 100V-277VAC outdoor power supplies certified to meet UL cUL and CE FCC safety approvals. The Power Transformer use low profile aluminum case with special input and output wiring makes the power solutions for different I.T.E, CCTV, Audio/Video, LED and home applications. Featuring PFC function of up to 0.95 and higher, IP65 IP67 environment Protection Rating for indoor or outdoor use, the H series ac to dc converter provide 5 years warranty and high efficient energy-saving.
Features:
． Super compact Aluminum case
． UL/cUL CE SAA UKCA FCC RoHS
． IP65 IP67 - Indoor or Outdoor Use
． Work in the temperature range of-40℃~+50℃ under natural air cooling and heat dissipation
． Auto-Reset Protection for input/output overvoltage protection, input/output overcurrent protection, over temperature protection, over power protection and short circuit protection
| Input Voltage | 100~277V AC 47~63Hz | |||
| Power Factor | PF≧0 98/115VAC, PF≧0 95/230VAC, PF≧0.9/277VAC, full load | |||
| Model | KS-300A-24 | KS-320A-24 | KS-320A-36 | KS-320A-48 |
| Output Voltage | 24V | 24V | 36V | 48V |
| Rated Current | 12.5A | 13.33A | 8.88A | 6.67A |
| Rated Power | 300W | 320W | 320W | 320W |
| Ripple & Noise (max.) | 250mVp-p | 250mVp-p | 250mVp-p | 250mVp-p |
| Dimenion (L*W*H) |
258*68*41mm |
|||
Dimension Drawing:
| Package | Piece/Carton(pcs) | Dimension/Carton(mm) | Dimension/Brown Box(mm) | Piece Weight(KG) | Gross Weight/Carton(KG) |
| OEM package | 10 | 315 x 305 x 300 | 303 x 145 x 55 | 1.68 | 17.5 |
