Customized 12V 5A 60W Desktop power supply

The desktop power adapter is a white desktop style, 60W 12Volt 5000mA universal ac input 100vac to 240vac single output power supplies with UL/cUL FCC PSE CE GS RCM safety approvals. The white led power supply is designed to meet US DoE Level VI energy efficiency standards and equipped with three standard AC inlets options for IEC320-C6, IEC320-C8 and IEC320-C14. This Power Adaptor laptop adopts the eco-friendly PC flame retardant plastic housing that the adapters can effectively prevent customers from electric hazard.

Usage: Display, Phone, Digital Camera, Game Player, Mobile Phone, Switching, Laptop

Output Type: DC, Single Output

Certification: CCC, UL, ROHS, TUV

Color: Black

Type: OEM

Connection: Desktop

Input: 100-240VAC 50-60HZ

Warranty: 3 Years

Efficiency: Level VI

Material: PC

Protections: OCP OVP SCP

DC Connector: Male 5.5*2.1mm Or Custom

DC Cord: 1.2m Or Custom

AC Plugs: US/ UK/ AU/ EU/ KR/ CN (optional)

Size: 114*51*31mm

Features

◆ Desktop style, up to 60W continuous power

◆ Universal AC input/ Full range

◆ Level VI energy efficiency

◆ Protections: Short circuit / Over voltage / Over current

◆ Class II power (without earth pin): IEC320-C8;

ClassⅠpower(with earth pin): IEC320-C6 or IEC320-C14

◆ Class 2 power units

◆ Pass LPS (limited power source)

◆ Compact Size, fully enclosed plastic case

◆ LED indicator for power on

◆ 100% full load burn-in test

◆ 3 years Warranty

Specifications

Dimensions LxWxH (in): 4.488 x 2.007 x 1.220
Dimensions LxWxH (mm): 114 x 51 x 31
Color: Black/ White
Input: 100-240V AC±10% 50/60Hz
Output: Constant voltage mode and Single output
Working Environment: -10℃-40℃ 5%-90%RH
Storage Environment: -20℃-85%℃ 5%-95%RH
No load power consumption: below 0.21W
Overshoot: 15% Max. When power supply at turn on or turn off
Cooling method: Natural Cooling down
RoHS compliant: Yes
Ripple/Noise:<150mV
Accuracy:±1%
Safety Standards: UL1310, UL60950, CSA22.2, TUV EN60950, AS/NZS 60950, GB4943, J60950(H22), K60950
Safety Approvals: UL CUL CE KC GS SAA RCM CB FCC RoHS

Applications: 3D Printer, Ultrasonic Humidifier, LCD Monitor, LED Lights, HDD Enclosure, CCTV, Car DVR, Digital Photo Frame, Mobile Phone, Laptop, Tablet PC, Refrigerators, Portable DVD, Set Top Box, Radio, Security System Products, Massage Products, Electronics Products etc

Model No.: ZF120A-1205000

Brand: KSPOWER

Place Of Origin: China

Output Type: Dc

Connection Method: Desktop, Plug In

Usage: LED

Output Type: DC

Certification: UL CE GS PSE...

Color: Black, Black/White

Type: OEM

Power Source: CV

Connection: Desktop

DC Connector: 5.5*2.1MM

AC Inlet: C8/C6/C14 optional

Packaging: 50 pcs put in one carton, sample is available

Productivity: 99999

Transportation: Ocean,Land,Air,Express,Others

Place of Origin: Made in China

Supply Ability: 99999

Certificate: ISO9001:2015, UL CE PSE CCC...

HS Code: 85044014

Port: Shenzhen

Payment Type: Paypal,Others,T/T

Incoterm: FOB,EXW,Express Delivery,CIF,DDP

Selling Units:Bag/Bags

Package Type:50 pcs put in one carton, sample is available
