30W 24V/1.25A AC-DC Lighting Adapter with 2.1mm Plug

30W 24V/1.25A AC-DC Lighting Adapter with 2.1mm Plug

The DC Power Supply adapter is a high quality, 24V1.25A 30W dc output desktop style constant voltage adaptor series with green LED indicator light for power on. This universal ac to dc adapter accepts full range 100~240V AC input voltage and lock type DC connector options. The RoHS ac adapter is a class 2 rated and certified for UL/cUL, GS, CE, RCM, KC, PSE,CCC, IEC/EN 62368 safety standards for AV and IT applications. We also provides 3 years warranty for the desktop style external power supply.

Features

◆ Desktop style, up to 30W continuous power

◆ Universal AC input/ Full range

◆ Level VI energy efficiency

◆ Protections: Short circuit / Over voltage / Over current

◆ Class II power (without earth pin): IEC320-C8;

ClassⅠpower(with earth pin): IEC320-C6 or IEC320-C14

◆ Pass LPS (limited power source)

◆ Compact Size, fully enclosed plastic case

◆ LED indicator for power on

◆ 100% full load burn-in test

◆ 3 years Warranty

Specifications

Dimensions LxWxH (in): 3.740 x 1.772 x 1.259
Dimensions LxWxH (mm): 95 x 45 x 32
Color: Black/ White
Input: 100-240V AC±10% 50/60Hz
Output: Constant voltage mode and Single output
Working Environment: -10℃-40℃ 5%-90%RH
Storage Environment: -20℃-85%℃ 5%-95%RH
No load power consumption: below 0.1W
Overshoot: 15% Max. When power supply at turn on or turn off
Cooling method: Natural Cooling down
RoHS compliant: Yes
Ripple/Noise:<150mV
Accuracy:±1%
Safety Standards: UL1310, UL60950, CSA22.2, TUV EN60950, AS/NZS 60950, GB4943, J60950(H22), K60950
Safety Approvals: UL CUL CE KC GS SAA RCM CB FCC RoHS

Applications: 3D Printer, Ultrasonic Humidifier, LCD Monitor, LED Lights, HDD Enclosure, CCTV, Car DVR, Digital Photo Frame, Mobile Phone, Laptop, Tablet PC, Refrigerators, Portable DVD, Set Top Box, Radio, Security System Products, Massage Products, Electronics Products etc

Mechanical Specification

Package

Model No.: KS39DU-2400125

Brand: KSPOWER

Place Of Origin: China

Output Type: Dc

Connection Method: Desktop, Plug In

Usage: Laptop LED LCD

Output Type: Single Output

Certification: TUV GS TUV KC UL PSE CCC...

Color: Black

Type: OEM

Connection: Desktop

Warranty: 3 Years

Material: PC

Input: 100-240VAC 50-60HZ

Efficiency: Level VI

Protections: OCP OVP SCP

DC Connector: Male 5.5*2.1mm Or Custom

DC Cord: 1.2m Or Custom

AC Plugs: US/ UK/ AU/ EU/ KR/ CN (optional)

Packaging: a. 1pc per inner brown box b. 50pcs per standard carton c. custom is acceptable d.sample is available

Productivity: 300000

Transportation: Ocean,Air,Express,Land,Others

Place of Origin: China

Supply Ability: 500000

Certificate: ISO9001, UL, CE, FCC, RCM, KC, RoHS, GS, PSE, CB...

HS Code: 850440

Port: Shenzhen

Payment Type: T/T,Paypal,Others

Incoterm: FOB,EXW,Express Delivery,DDP,DDU

Selling Units:Piece/Pieces

Package Type:a. 1pc per inner brown box b. 50pcs per standard carton c. custom is acceptable d.sample is available
