24V Series UL Class 2 Switching Power Supply

The desktop class 2 power adapter is a wall mount or desktop style, universal ac input 100vac to 240vac single output 24V dc power supplies with UL/cUL FCC PSE CE GS RCM safety approvals. The led Power Supply is designed to meet US DoE Level VI energy efficiency standards and equipped with three standard AC inlets options for IEC320-C6, IEC320-C8 and IEC320-C14. This Class 2 Power Adaptor adopts the eco-friendly PC flame retardant plastic housing that the adapters can effectively prevent customers from electric hazard.

Features

◆ Wall mount or Desktop style, 24 Volt Class 2 Power Supplies

◆ Universal AC input/ Full range

◆ Level VI energy efficiency

◆ Protections: Short circuit / Over voltage / Over current

◆ Class II power (without earth pin): IEC320-C8;

ClassⅠpower(with earth pin): IEC320-C6 or IEC320-C14

◆ Pass LPS (limited power source)

◆ Compact Size, fully enclosed plastic case

◆ LED indicator for power on

◆ 100% full load burn-in test

◆ 3 years Warranty

Specifications

Color: Black/ White
Input: 100-240V AC±10% 50/60Hz
Output: Constant voltage mode and Single output
Working Environment: -10℃-40℃ 5%-90%RH
Storage Environment: -20℃-85%℃ 5%-95%RH
No load power consumption: below 0.21W
Overshoot: 15% Max. When power supply at turn on or turn off
Cooling method: Natural Cooling down
RoHS compliant: Yes
Ripple/Noise:<150mV
Accuracy:±1%
Safety Standards: UL1310, UL60950, CSA22.2, TUV EN60950, AS/NZS 60950, GB4943, J60950(H22), K60950
Safety Approvals: UL CUL CE KC GS SAA RCM CB FCC RoHS

Applications: 3D Printer, Ultrasonic Humidifier, LCD Monitor, LED Lights, HDD Enclosure, CCTV, Car DVR, Digital Photo Frame, Mobile Phone, Laptop, Tablet PC, Refrigerators, Portable DVD, Set Top Box, Radio, Security System Products, Massage Products, Electronics Products etc

Model No.: ZF120A-2403000

Brand: KSPOWER

Place Of Origin: China

Output Power: 1 - 50w, 51 - 100w

Output Type: Single

The Output Voltage: 24v

Connection: Desktop

Output Type: Single Output

Warranty: 3 Years

DC Connector: Male 5.5*2.1mm Or Custom

DC Cord: 1.2m Or Custom

Color: Black / White

Usage: LED Lighting ...

Type: OEM

Material: PC

Input: 100-240VAC 50-60HZ

Efficiency: Level VI

Protections: OCP OVP SCP

AC Plugs: US/ UK/ AU/ EU/ KR/ CN (optional)

Certification: UL cUL Class 2 FCC RoHS..

Packaging: a. 1pc per inner brown box b. 50pcs per standard carton c. custom is acceptable d.sample is available

Productivity: 200000

Transportation: Ocean,Air,Express,Land,Others

Place of Origin: China

Supply Ability: 500000

Certificate: ISO9001:2015, UL cUL Class 2 CE FCC RoHS ...

HS Code: 850440

Port: Shenzhen

Payment Type: T/T,Paypal,Others

Incoterm: FOB,EXW,Express Delivery

Selling Units:Piece/Pieces

Package Type:a. 1pc per inner brown box b. 50pcs per standard carton c. custom is acceptable d.sample is available

Picture Example:
