16.8VDC Wall Plug charger for 4S Li-ion battery

16.8VDC 1A/2A/3A/3.5A Wall Charger for 4S Li-ion Battery

The 16.8V DC Power Battery Charger is a highly reliable, CC + CV wall-mounted style single-output Ac Dc Power Adaptor Charger series for 4S li-ion batteries, accept output current range from 1A-3.5A option. This safety mark battery charger is equipped with an fixed AC plug EU / KR / US / AU / UK / CN type and Class II rated without earth pin, accepting the universal AC input 100-240V voltage range. Featuring the working efficiency of level VI, low no-load power consumption below 0.1W, wall plug in power charger is compliant with the latest VI energy regulation. The universal ac dc adapter provides safety protections for over current, over voltage and short circuit.

Features

◆ Wall mount style, charger for Li-ion batteries(lithium iron and lithium manganese)

◆ Constant voltage and constant current mode

◆ Universal AC input/ Full range

◆ Level VI energy efficiency

◆ Protections: Short circuit / Over voltage / Over current

◆ Class II power (without earth pin)

◆ Class 2 power units

◆ Pass LPS (limited power source)

◆ Compact Size, fully enclosed plastic case

◆ 100% full load burn-in test

◆ 3 years Warranty

Specifications

Dimensions LxWxH (in): 3.031 x 1.850 x 1.220
Dimensions LxWxH (mm): 77 x 47 x 31
Color: Black/ White
Input: 100-240V AC±10% 50/60Hz
Output: DC and Single output
Working Environment: -10℃-40℃ 5%-90%RH
Storage Environment:-20℃-85%℃ 5%-95%RH
No load power consumption: below 0.15W
Overshoot: 15% Max. When Power Supply at turn on or turn off
Cooling method: Natural Cooling down
RoHS compliant: Yes
Ripple/Noise:<150mV
Accuracy:±1%
Safety Standards: UL1310, UL62368, CSA22.2, TUV-GS CE IEC/EN62368, AS/NZS 62368, GB4943, J62368, K60950
Safety Approvals: UL CUL CE KC GS SAA RCM CB FCC RoHS

Green adaptor with charging function

For high surge current equipment
