The wall mounted power supplies is a highly reliable, 36W constant voltage mode wall-mounted style single-output Ac Dc Power Adaptor series. This energy saving Power Supply 36w is equipped with an AC plug USA type and Class 2 rated without earth pin, accepting the universal AC input voltage range from 100V-240V. Featuring the working efficiency of level VI, low no-load power consumption below 0.1W, wall plug in power supply is compliant with the latest USA energy regulation. Universal ac dc adapters provides safety protections for over current, over voltage and short circuit.
Features
◆ US blade wall-mount style, up to 36W continuous power
◆ Universal AC input/ Full range
◆ Level VI energy efficiency
◆ Protections: Short circuit / Over voltage / Over current
◆ Class II power (without earth pin)
◆ Class 2 power units
◆ Pass LPS (limited power source)
◆ Compact Size, fully enclosed plastic case
◆ 100% full load burn-in test
◆ 3 years Warranty
Specifications
Dimensions LxWxH (in): 3.031 x 1.850 x 1.220
Dimensions LxWxH (mm): 77 x 47 x 31
Color: Black/ White
Input: 100-240V AC±10% 50/60Hz
Output: Constant voltage mode and Single output
Working Environment: -10℃-40℃ 5%-90%RH
Storage Environment:-20℃-85%℃ 5%-95%RH
No load power consumption: below 0.15W
Overshoot: 15% Max. When power supply at turn on or turn off
Cooling method: Natural Cooling down
RoHS compliant: Yes
Ripple/Noise:<150mV
Accuracy:±1%
Safety Standards: UL1310, UL62368, J62368, TUV-GS CE IEC/EN62368, AS/NZS 62368, GB4943, K60950
Safety Approvals: UL CUL CE KC GS SAA RCM CB FCC RoHS
Applications: 3D Printer, LCD Monitor, LED Lights, CCTV, Digital Photo Frame, Mobile Phone, Tablet PC, Refrigerators, Portable DVD, Set Top Box, Security System Products, Massage Products, Electronics Products etc
|
Mechanical Specification
|
| Package | Piece/Carton(pcs) | Dimension/Carton(mm) | Dimension/Brown Box(mm) | Piece Weight(KG) | Gross Weight/Carton(KG) |
| OEM package | 60 | 360 x 352 x 250 | 68 x 55 x 115 | 0.15 | 10 |
Model No.: KS39DU-1200300CU
Brand: KSPOWER
Place Of Origin: China
Output Type: Dc
Connection Method: Plug In, Desktop
Usage: Laptop
Output Type: Single Output
Color: Black
Type: Oem
Connection: Plug In
Warranty: 3 Years
Material: Pc
Input: 100-240vac 50-60hz
Efficiency: Level Vi
Protections: Ocp Ovp Scp
DC Connector: Male 5.5*2.1mm Or Custom
DC Cord: 1.2m Or Custom
AC Plugs: Us/ Uk/ Au/ Eu/ Kr/ Cn (Optional)
Certification: ISO9001:2015,UL CE FCC RCM KC GS CCC PSE
Packaging: a. 1pc per inner brown box b. 60pcs per standard carton c. custom is acceptable d. sample is available
Productivity: 200000
Transportation: Ocean,Air,Express,Land,Others
Place of Origin: China
Supply Ability: 500000
Certificate: ISO9001:2015,UL CE FCC RCM KC GS CCC PSE
HS Code: 850440
Port: Shenzhen
Payment Type: T/T,Paypal,Others
Incoterm: FOB,EXW,Express Delivery,DDP,DDU
